SMC-523 Hydraulic Slipform Paver for Highway Curb Paving 125x50cm

Name: SMC523 Hydraulic Slipform Paver for Highway Curb Paving 125x50cm
Brand: Siming
Price: 39 USD

Quality SMC-523 Hydraulic Slipform Paver for Highway Curb Paving 125x50cm for sale

Place of Origin : Jiangsu, China

Brand Name : Siming

MOQ : 1

Price : $39,000

Weight : 2400 kg

Engine Model : Yanmar4TNV88/Quanjiao QC490G

Hydraulic Pump : American Sauer variable displacement pump KRR038

Paving Width : 0-1250mm

Paving Height : 0-500mm

Transport Size : length 352× width 150× height 130 cm

Host Weight : 3100kg

Paving Size : curb width 125× height 50 cm

Paving Speed : 0~12m/min

Driving Speed : 0~30m/min

Core Components : Engine, hydraulic pump, vibrating spear

Fully Hydraulic : Yes

Single Track Drive : Hydraulic

Automatic Leveling : High-precision

Built-in Vibration : Yes

Contact Now

Product description：

Application range
Suitable for the construction of highways and municipal roads, including curbs, slope protection, and drainage ditches.

Three boxes volume
Paving width	0-1250mm
Paving height	0-500mm
Engine model	Yanma 4TNV88/ QC490G
Hydraulic pump	USA Sa variable pump KRR038
Transport size (cm)	length 352× width 150× height 130
Host weight	3100kg
Paving size (cm)	curb width 125× height 50
Paving speed	0~12m/min
Driving speed	0~30m/min

SMC-523 Hydraulic Slipform Paver for Highway Curb Paving 125x50cm

Features
1. The human-machine interface is friendly and intuitive.
2. This machine meets the requirements of high efficiency and environmental protection, with sufficient power surplus to cope
with various harsh working conditions.

3. Single track hydraulic drive, smooth walking, good adhesion.
4. Equipped with high-precision automatic leveling and automatic steering functions, it can accurately pave according to specified elevation and line type.

5. Use a built-in vibration rod to ensure smooth surface and dense interior of the concrete after paving and forming.
6. Equipped with a complete set of high-pressure water flushing devices and various random tools for easy field work and
maintenance of the machine

1.Q: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted

2.Q: What certificates are available in Machinery?
A: For the certificate, we have ISO certificate,

3.Q: What about the delivery time?
A: 7-30 days after receiving the deposit.

4.Q: What about the warranty time?
A:: 12 months after shipment .

5. Q: What about the Minimum Order Quantity?
A:: The MOQ is 1 pcs
